Description
For boats from 8 to 14 metres (26 - 46ft)
A rope only anchor winch that allows for easy installation.
Also suitable for general line hauling applications on larger boats.
Features:
- Mounts easily in any deck thickness (stud dependent)
- Suitable for vertical or horizontal mounting
- Patented epicyclical gearbox allows higher performance of the motor
- Permanent magnet motor for greater output and reduced power consumption
- IP66 watertight motor
- AISI 316 grade stainless steel base
- 3 year warranty from the date of sale
Standard Inclusions:
- Clutch Release and Manual Life Handle
- Isolator/Circuit Breaker Panel
- Reversing Solenoid
- Deck thickness: 20 - 30mm
Optional Additions:
- Remote Up/Down Panel Switch
| Model | TM3 600 | TM3 1000 |
|---|---|---|
| Watts | 500w | 800w |
| Volts | 12v | 12v or 24v |
| Amps | 40amps | 80/40Amps |
| Maximum Pull | 620kg | 820kg |
| Maximum Working Load | 200kg | 290kg |
| Maximum Chain Speed | 15.4m/min | 25.8m/min |
| Drive Shaft | Vertical | Vertical |
| Capstan Option | Yes | Yes |
| Chain/Rope Gypsy | No | No |
Enquiry Form
Vertical Capstan - Totem Series
Enquiry Form
Specifications
| SKU | JPW-P-QFSTM30600120B00 |
| Brand | Quick Nautical Equipment |
